- material: aluminium
- 160mm suspension travel
- 27.5” x 2,6” max. wheelsize
- 148x12mm axle standard
- intube *
Rahmengrössen Short, Mid, Long, XLong
Farbe GUNMETAL GREY (BLACK)
- Air
- 160mm suspension travel
- Tapered
- 44mm fork offset
- 29x2.6" max wheelsize
Federbein Marzocchi Bomber Air
- LinkGlide
- 160mm for all sizes
Schalthebel Shimano MT500-IL / Shimano XT M8130 11
- 4 piston
- 203mm
Steuersatz Acros ICR Blocklock
Spacer 2*10mm, 1*2.5mm
Griffe MERIDA EXPERT TR
Schalthebelklemme JAGWIRE FLEX-SL:CP
- 11-50 teeth
- 11 speed
- 30mm inner width
- material: aluminium
- Tubeless ready (tubeless tape installed)
- front 29"
- rear 27.5"
Felgenband Stans 30mm tubeless tape installed
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
- black nipples
- 29x2.4"
- fold
- TR
- Enduro casing
- Soft compund
- 27.5x2.4"
- fold
- Enduro casing, soft compound
Kette Shimano LG500
Pedale VP VPE-533
- 34.9mm diameter
- 0mm setback
- travel seatpost: 125mm (XS), 150mm (S), 170mm (M), 200mm (L), 230mm (XL)
- V-mount adapter
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Schutzbleche RF-001 mini fender
- reverse MERIDA Custom Mount
Rücklicht USB REAR Light CG-214RG
Motor Bosch Performance Line CX
- 800Wh
Display Bosch Purion 400
Switch Bosch Mini Remote
weighed at frame size M
Zulässiges Gesamtgewicht 140 kg
| Rahmengröße | Short | Mid | Long | XLong |
| Laufradgröße | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" |
| ST Sitzrohrlänge (mm) | 380 | 405 | 430 | 455 |
| TT Oberrohrlänge (mm) | 556 | 584 | 609 | 636 |
| CS Hinterbaulänge (mm) | 446 | 446 | 446 | 446 |
| HTA Steuerrohrwinkel (°) | 65 | 65 | 65 | 65 |
| STA Sitzrohrwinkel effektiv (°) | 78.5 | 78.5 | 78.5 | 78.5 |
| BD Tretlagerabsenkung (mm) | 20 | 20 | 20 | 20 |
| HT Steuerrohrlänge (mm) | 105 | 115 | 115 | 125 |
| FL Gabeleinbaulänge (mm) | 580 | 580 | 580 | 580 |
| Fo Fork Offset Mm | 44 | 44 | 44 | 44 |
| R Reach (mm) | 425 | 450 | 475 | 500 |
| S Stack (mm) | 644 | 653 | 653 | 662 |
| WB Radstand (mm) | 1202 | 1231 | 1256 | 1285 |
| SH Überstandshöhe (mm) | 745 | 748 | 751 | 754 |
