- material: aluminium
- 142mm suspension travel
- 27.5" x 2,6” max. wheelsize
- 148x12mm axle standard
- intube *
Rahmengrössen Short, Mid, Long, XLong
Farbe GUNMETAL GREY (BLACK)
- Air
- 140mm suspension travel
- Tapered
- 44mm fork off set
- 29x2.6" max wheelsize
Federbein SR Suntour Edge X
- 160mm for all sizes
Schalthebel Shimano MT500-L / Shimano Cues U6000-10
- 4 piston
- 200mm
Steuersatz FSA CRII NO.80
Spacer 2*10mm, 1*2.5mm
Griffe MERIDA COMP TR
Schalthebelklemme JAGWIRE FLEX-SL:CP
- 11-48 teeth
- 10 speed
- 110x15mm width front hub
- 148x12mm width rear hub
- 28mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- front 29"
- rear 27.5"
Felgenband Stans 30mm tubeless tape installed
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
- black nipples
- 29x2.5"
- EXO wire
- tubeless ready
- 27.5x2.4" wired
- tubeless ready
Kette Shimano LG500
Pedale VP VPE-527
- 34.9mm diameter
- 0mm setback
- travel seatpost: 125mm (XS), 150mm (S), 170mm (M), 200mm (L), 230mm (XL)
- V-mount
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Schutzbleche RF-001 mini fender
Scheinwerfer USB rechargable Chance Good CG-119PG-BLACK(1)
Rücklicht USB rechargable Chance Good CG-404RG-BLK
Motor Bosch Performance Line CX
- 800Wh
Display Bosch Purion 200
Zulässiges Gesamtgewicht 140 kg
| Rahmengröße | Short | Mid | Long | XLong |
| Laufradgröße | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" |
| ST Sitzrohrlänge (mm) | 380 | 405 | 430 | 455 |
| TT Oberrohrlänge (mm) | 556 | 584 | 609 | 636 |
| CS Hinterbaulänge (mm) | 446 | 446 | 446 | 446 |
| HTA Steuerrohrwinkel (°) | 65 | 65 | 65 | 65 |
| STA Sitzrohrwinkel effektiv (°) | 78.5 | 78.5 | 78.5 | 78.5 |
| BD Tretlagerabsenkung (mm) | 20 | 20 | 20 | 20 |
| HT Steuerrohrlänge (mm) | 105 | 115 | 115 | 125 |
| FL Gabeleinbaulänge (mm) | 580 | 580 | 580 | 580 |
| Fo Fork Offset Mm | 44 | 44 | 44 | 44 |
| R Reach (mm) | 425 | 450 | 475 | 500 |
| S Stack (mm) | 644 | 653 | 653 | 662 |
| WB Radstand (mm) | 1202 | 1231 | 1256 | 1285 |
| SH Überstandshöhe (mm) | 745 | 748 | 751 | 754 |
