- Rahmen: SPEEDER LITE II
- * material: aluminium
* 700C wheelsize
* 100x9/135x9mm axle standard
* BSA bottom bracket standard
- Gabel: MERIDA SPEEDER CF2
- * Tapered
* material: carbon
- Bremshebel: Shimano MT-200
- Vorderradbremse: Shimano MT-200
- Hinterradbremse: Shimano MT-200
- Bremsscheibe vorn: Shimano RT10
- * 160 mm
- Bremsscheibe hinten: Shimano RT10
- * 160 mm
- Kette: KMC X11
- Kettenblatt: Shimano 105
- * 50-34 teeth
* 170 mm-XS/S, 172,5 mm-SM/ML, 175 mm-L/XL
- Kurbelgarnitur: 170 mm-XS/S, 172,5 mm-SM/ML, 175 mm-L/XL
- Innenlager: Shimano BB-RS500 BSA
- Umwerfer: Shimano 105
- Schaltwerk: Shimano 105
- * GS
- Kassette: Shimano CS-R7000
- * 11-32 teeth
* 11 speed
- Pedale: VP VPE-891
- Griffe: MERIDA EXPERT EC
- Lenker: MERIDA EXPERT CC
- * material: aluminium
* 600mm width
* Flat
- Vorbau: MERIDA EXPERT CC
- * material: aluminium
* 31.8mm diameter
* 5° stem angle
* 80 mm-XS, 90 mm-S, 100 mm-SM/ML, 110 mm-L/XL
- Steuersatz: MERIDA M2331 Neck
- Kompressor: PT-1709-822
- Vorderradnabe: Joytech D481SBT-SC-CL
- * 100x9mm width front hub
* 28 spoke holes
* centerlock
- Hinterradnabe: Joytech D482TSBT-SC-CL
- * 135x9mm width rear hub
* 28 spoke holes
* centerlock
- Vorderachse: QR
- Hinterachse: QR
- Felge: MERIDA COMP SL
- * 17mm inner width
* 22mm height
* material: aluminium
- Sattel: MERIDA COMP SL
- * V-mount
- Sattelstütze: MERIDA COMP CC
- * material: aluminium
* 30.9mm diameter
* 12mm setback
- Schalthebel vorn: Shimano SL-RS700
- Schalthebel hinten: Shimano SL-RS700
- Vorderreifen: Maxxis Detonator
- * 700x32C
* fold
- Hinterreifen: Maxxis Detonator
- * 700x32C
* fold
- Gewicht: 10
- weighed at frame size S-M without pedals
