- material: carbon
- 700x30C max. wheelsize
- 100x12 / 142x12mm axle standard
- Pressfit 86,5
Rahmengrössen 3XS, XXS, XS, S, M, L, XL
Farbe METALLIC BLACK (FLASH BCP)
- material: carbon
- 700x30C max. wheelsize
- 52-36 teeth
- left arm 4IIII PM
Schaltwerk Shimano 105 Di2
Kurbel 160 mm-3S, 165 mm-XXS/XS, 170 mm-S/M, 172.5 mm-L/XL
Schalthebel Shimano 105 disc Di2
- Disc
- 160mm
Bremshebel Shimano 105
Steuersatz FSA ACR NO.55R
- Pressfit 86.5
Spacer MERIDA TEAM ONE-PIECE INTEGRATED 2*10mm, 1*5mm
Griffe MERIDA ROAD EXPERT
- 11-34 teeth
- 12 speed
- 100x12mm width front hub
- 142x12mm width rear hub
- 22IWR
- 40mm height
- Centerlock
- material: carbon
Felgenband DT Swiss tubeless ready W:25MM/L:66M
- 100x12mm width front hub
- 28 spoke holes
- Centerlock
- 12x142mm width rear hub
- 28 spoke holes
- Centerlock
- including removable lever
- 6/4mm allen key
Speichen PSR TB2016 24H/24H ??
- 700x28C
- fold
- tubeless ready
Kette Shimano M6100-12
Umwerfer Shimano 105 Di2
- 27.2mm diameter
- 0mm setback
- Carbon
- 6% recycled and 23% nature material
- V-mount
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Motor Disc cooler F/R
Akku Protective Sleeve
| Rahmengröße | 3XS | XXS | XS | S | M | L | XL |
| Laufradgröße | 28" | 28" | 28" | 28" | 28" | 28" | 28" |
| ST Sitzrohrlänge (mm) | 400 | 435 | 458 | 481 | 501 | 521 | 550 |
| TT Oberrohrlänge (mm) | 505 | 520 | 535 | 545 | 560 | 575 | 590 |
| CS Hinterbaulänge (mm) | 408 | 408 | 408 | 408 | 408 | 408 | 408 |
| HTA Steuerrohrwinkel (°) | 70.5 | 70.5 | 72 | 72.5 | 73.5 | 73.5 | 74 |
| STA Sitzrohrwinkel effektiv (°) | 75.5 | 74.5 | 74 | 74 | 73.5 | 73 | 73 |
| BD Tretlagerabsenkung (mm) | 70 | 70 | 70 | 66 | 66 | 66 | 66 |
| HT Steuerrohrlänge (mm) | 100 | 105 | 112 | 128 | 140 | 155 | 176 |
| FL Gabeleinbaulänge (mm) | 385 | 385 | 385 | 385 | 385 | 385 | 385 |
| R Reach (mm) | 373 | 377 | 383 | 390 | 395 | 400 | 409 |
| S Stack (mm) | 512 | 517 | 529 | 542 | 557 | 571 | 593 |
| WB Radstand (mm) | 979 | 985 | 982 | 989 | 990 | 1000 | 1010 |
| SH Überstandshöhe (mm) | 700 | 721 | 745 | 765 | 782 | 800 | 823 |
