| Modell + HP/EP | SCULTURA ENDURANCE RIVAL-EDITION HP1 |
| Farbe (Herstellerbezeichnung) | GUNMETAL GREY |
| Rahmen | SCULTURA ENDURANCE CF3 II- material: carbon
|
| Gabel | SCULTURA ENDURANCE CF3 DISC- material: carbon
|
| Bremse vorn | Sram ED Rival eTap AXS- Hydraulic disc |
| Bremse hinten | Sram ED Rival eTap AXS- Hydraulic disc |
| Bremshebel | Sram ED Rival eTap AXS |
| Bremsscheibe vorn | Sram DB ROTOR CENTERLOCK PACELINE- 160mm |
| Kettenblatt | Sram Rival eTap AXS- 48-35 teeth
|
| Kurbelgarnitur | 165mm-XXS, 170 mm-XS/S, 172.5 mm-M, 175 mm-L/XL |
| Schalthebel vorn | Sram Rival eTap AXS |
| Schalthebel hinten | Sram Rival eTap AXS- SS |
| Schaltwerk | Sram Rival eTap AXS- SS |
| Umwerfer | Sram Rival eTap AXS |
| Kassette | CS XG 1250 D1- 10-36 teeth
|
| Kette | SRAM Rival 12s |
| Lenker | MERIDA EXPERT SL- material: aluminium
|
| Griffe | MERIDA ROAD Expert |
| Vorbau | MERIDA EXPERT CW- 31.8mm diameter
|
| Steuersatz | MERIDA-8151 Semi integrated HS |
| Sattel | MERIDA EXPERT SL- V-mount
|
| Sattelstütze | MERIDA TEAM SL- 27.2mm diameter
|
| Vorderreifen | Continental GP5000 AllSeason TR- 700x32C
|
| Hinterreifen | Continental GP5000 AllSeason TR- 700x32C
|
| Laufradsatz | Fulcrum Racing 800 DB- 100x12mm width front hub
|
| Innenlager | Sram Pressfit Dub, Presfit 86.5 |
| Zuläss. Gesamtgewicht | 120 kg |
Weitere Informationen zu diesem Artikel finden Sie auf der
Homepage des Herstellers.
- material: carbon
- 700x35C max./ 700x32C (with fender) max. wheelsize
- 100x12/ 142x12mm axle standard
- BB86 bottom bracket standard
Rahmengrössen XS, S, M, L, XL
Farbe GUNMETAL GREY (CHAMELEON GREEN)
- material: carbon
- 700x35C max. wheelsize
- 48-35 teeth
- 165mm-XXS, 170 mm-XS/S, 172.5 mm-M, 175 mm-L/XL
Schalthebel Sram Rival eTAP AXS HRD
- Hydraulic Disc
Bremshebel Sram ED Rival eTap AXS
- w/o crown race
Innenlager Sram Pressfit Dub, Presfit 86.5
Spacer MERIDA-1321
Griffe MERIDA ROAD Expert
- 10-36 teeth
- 12 speed
- 100x12mm width front hub
- 142x12mm width rear hub
- 19mm inner width
- 34mm height
- Centerlock
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- including removable lever
- 6/4mm allen key
- 700x32C
- fold
Kette Sram Rival 12s
Umwerfer Sram Rival eTap AXS
- 27.2mm diameter
- 15mm setback
- Carbon
- S-Flex
- V-mount
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Zulässiges Gesamtgewicht 120 kg
| Rahmengröße | XS | S | M | L | XL |
| Laufradgröße | 28" | 28" | 28" | 28" | 28" |
| ST Sitzrohrlänge (mm) | 470 | 490 | 510 | 530 | 560 |
| TT Oberrohrlänge (mm) | 524 | 538 | 553 | 568 | 583 |
| CS Hinterbaulänge (mm) | 418 | 418 | 418 | 418 | 418 |
| HTA Steuerrohrwinkel (°) | 71 | 72 | 73 | 73 | 73.5 |
| STA Sitzrohrwinkel effektiv (°) | 74 | 74 | 73.5 | 73.5 | 73.5 |
| BD Tretlagerabsenkung (mm) | 66 | 66 | 66 | 66 | 66 |
| HT Steuerrohrlänge (mm) | 152 | 161 | 177 | 197 | 222 |
| FL Gabeleinbaulänge (mm) | 380 | 380 | 380 | 380 | 380 |
| R Reach (mm) | 366 | 376 | 380 | 389 | 397 |
| S Stack (mm) | 552 | 565 | 584 | 603 | 629 |
| WB Radstand (mm) | 997 | 1001 | 1001 | 1017 | 1026 |
| SH Überstandshöhe (mm) | 767 | 785 | 803 | 823 | 852 |
Angaben zur Produktsicherheit
Hersteller:
MERIDA INDUSTRY CO., LTD., P.O. Box 56, Yuanlin, Taiwan R.O.C.
Kontakt: www.merida-bikes.com
Verantwortliche Person:
MERIDA & CENTURION Germany GmbH, Blumenstraße 49-51, 71106 Magstadt, Deutschland
Kontakt: www.mcg-parts.de
