- Rahmen: ONE-TWENTY RC LITE
- * 100mm suspension travel * material: aluminium * 29 wheelsize * 148x12mm axle standard * BB92 bottom bracket standard
- Federbein: Rock Shox Deluxe Select+
- * lockout
- Remote-Hebel: RM ONELOC SPRINT RIGHT FORK
- Gabel: Rock Shox Reba RL
- * Air * 120mm suspension travel * Tapered * remote lockout * 51mm fork offset
- Vorderradbremse: Shimano MT-500
- * 2 piston
- Hinterradbremse: Shimano MT-500
- * 2 piston
- Bremsscheibe vorn: Shimano RT54
- * 180 mm
- Bremsscheibe hinten: Shimano RT54
- * 180 mm
- Kette: Shimano SLX
- Kettenblatt: Shimano XT
- * 32 teeth * 170 mm-S, 175 mm-M up
- Kurbelgarnitur: 170 mm-S, 175 mm-M up
- Innenlager: Shimano BB71-41A pressfit
- Schaltwerk: Shimano XT M8100 Shadow+
- Kassette: Shimano M7100
- * 10-51 teeth * 12 speed
- Griffe: MERIDA COMP EC
- Lenker: MERIDA EXPERT CC
- * material: aluminium * 740mm width * flat
- Vorbau: MERIDA EXPERT CC
- * material: aluminium * 31.8mm diameter * -6° stem angle * 70 mm all sizes
- Steuersatz: FSA NO.47/50
- Kompressor: AL cap with STS bolt+ ST stop nut
- Vorderradnabe: Shimano SLX
- * 110x15mm width front hub * 32 spoke holes * Centerlock
- Hinterradnabe: Shimano SLX
- * 148x12mm width rear hub, 32 spoke holes * Centerlock
- Hinterachse: MERIDA COMP TR
- Felge: MERIDA EXPERT CC
- * 22.8mm inner width * material: aluminium * Tubeless ready (tubeless tape and valves not included)
- Sattel: MERIDA COMP CC
- Sattelstütze: MERIDA COMP TR
- * 30.9mm diameter * 0mm setback * S: 100mm travel seatpost - M/L/XL 125mm travel seatpost
- Schalthebel hinten: Shimano XT
- Vorderreifen: Maxxis Rekon Race
- * 29x2.35" * fold * TR EXO
- Hinterreifen: Maxxis Rekon Race
- * 29x2.35" * fold * TR EXO
- Schutzbleche: MERIDA MTB lite-front
- Zubehör: MERIDA Multitool with saddlebox
- Gewicht: 13.76
- weighed at frame size L and 29" wheels without pedals
