Weitere Informationen zu diesem Artikel finden Sie auf der
Homepage des Herstellers.
- 171mm suspension travel mullet / 162mm suspension travel 29"
- material: carbon
- 29x2.5" max. wheelsize
- 148x12mm axle standard
- BSA bottom bracket standard
Rahmengrössen Mid, Long, XLong
Farbe FALL GREEN (FLASH BCP)
- Air
- 170mm suspension travel
- Tapered
- 44mm fork offset
- 29x2.8" max. wheelsize
- electric suspension system
- adjustable low speed compression
- electric suspension system
- 32 teeth
- 2 guards
- wireless
- T-Type
- 32 teeth
- 170 mm for
Schalthebel Shimano SL -MT800-IL / Sram AXS POD Ultimate Controller
- 4 piston
- 203 mm
Steuersatz MERIDA 8151
Innenlager Sram BB DUB BSA 73 MTB WIDE
Spacer 2*HTW-301-10mm, 1*HTW-301-5mm
Griffe MERIDA EXPERT EC
Schalthebelklemme Mr.Control-ADP-ISPEC-EV-R
- 10-52 teeth
- 12 speed
- 110x15mm width front hub
- 148x12mm width rear hub
- 28mm inner width
- Centerlock
- Sram XD
- material: carbon
- Tubeless ready (tubeless tape and valves included)
- Lifetime warranty
- rear 27.5" up to Size M, rear 29" L & XL
- including removeable lever, 6/4mm allen key
- 29x2.5"
- fold
- TR DD 3C MaxxGrip
- 27.5x2.4" XS/S/M 29x2.4" L/XL
- fold
- TR DD 3C MaxxTerra
- Flattop
Kettenschutz MRP AMg V2 Alloy 26-32T
- 34.9mm diameter
- 0mm setback
- 30-230mm travel seatpost
- V-mount
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Schutzbleche Rock Shox ZEB Fender
weighed at frame size MID
Zulässiges Gesamtgewicht 135 kg
| Rahmengröße | Mid | Long | XLong |
| Laufradgröße | 29/27.5" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 425 | 445 | 470 |
| TT Oberrohrlänge (mm) | 589 | 621 | 653 |
| CS Hinterbaulänge (mm) | 434 | 437.5 | 437.5 |
| HTA Steuerrohrwinkel (°) | 64 | 64 | 64 |
| STA Sitzrohrwinkel effektiv (°) | 79 | 79 | 79 |
| BD Tretlagerabsenkung (mm) | 7 | 27.5 | 27.5 |
| HT Steuerrohrlänge (mm) | 95 | 105 | 120 |
| FL Gabeleinbaulänge (mm) | 581 | 581 | 581 |
| R Reach (mm) | 470 | 498 | 525 |
| S Stack (mm) | 615 | 625 | 638 |
| WB Radstand (mm) | 1242 | 1275 | 1308 |
| SH Überstandshöhe (mm) | 737 | 736 | 776 |
