| Modell + HP/EP | ONE-FORTY 500 HP1 |
| Farbe (Herstellerbezeichnung) | SILK DARK STRAWBERRY |
| Rahmen | ONE-FORTY LITE III- 143mm suspension travel 29"
|
| Gabel | Marzocchi Z2- Air
|
| Dämpfer | Rock Shox Deluxe Select+- lockout |
| Bremse vorn | Shimano Deore M6120- 4 piston |
| Bremse hinten | Shimano Deore M6120- 4 piston |
| Bremsscheibe vorn | Shimano RT30- 203 mm |
| Kettenblatt | Race Face Ride- 32 teeth
|
| Kurbelgarnitur | 170 mm-S, 175 mm-M up |
| Schalthebel hinten | Shimano Deore M5100 Shadow+ |
| Schaltwerk | Shimano Deore M5100 Shadow+ |
| Kassette | Shimano Deore M5100- 11-51 teeth
|
| Kette | KMC X11 |
| Lenker | MERIDA TEAM TR- material: aluminium
|
| Griffe | MERIDA EXPERT EC |
| Vorbau | MERIDA EXPERT eTRII- material: aluminium
|
| Steuersatz | MERIDA-8158 1-1/8"-1.5" cartridge bearing set |
| Sattel | MERIDA COMP SL- V-mount |
| Sattelstütze | MERIDA EXPERT TR II- 34.9mm diameter
|
| Vorderreifen | Maxxis Minion DHF- 29x2.5"
|
| Hinterreifen | Maxxis Dissector- 29x2.4"
|
| Nabe vorn | Shimano MT400-B- 110x15mm width front hub
|
| Nabe hinten | Shimano MT400-B- 148x12mm width rear hub
|
| Felge | MERIDA COMP TR- 29mm inner width
|
| Innenlager | Race Face BSA 68/73 – 24mm |
| Zuläss. Gesamtgewicht | 135 kg |
