- material: carbon
- 160mm suspension travel
- 29x2,4" max. wheelsize
- 148x12mm axle standard
- fixed battery
Rahmengrössen XShort, Short, Mid, Long, XLong
Farbe GUNMETAL GREY (BLACK DOTS)
- Air, 160mm suspension travel
- Tapered
- 44mm fork offset
- 29x2.6" max wheelsize
Federbein Fox Float X Factory
Schaltwerk Sram XX Eagle Transmission AXS
- 165 mm for all sizes
Schalthebel Fox Transfer remote / Sram AXS Pod Ultimate Controller
- 4 piston
- 200mm
Steuersatz Acros ICR MERIDA INTEGRATED neck w/ Blocklock
Spacer 2*10mm, 1*2.5mm
Griffe MERIDA EXPERT EC
- 10-52
- 12 speed
- 110x15mm width front hub
- 148x12mm width rear hub
- 30mm inner width
- 6-Bolt
- SRAM XD
- material: carbon
- Tubeless ready (tubeless tape and valves included)
- including removeable lever, 6/4mm allen key
- 29x2.5 "
- fold
- TR EXO+ 3C MaxxGrip
- 29x2.4 "
- fold
- TR EXO+ 3C MaxxTerra
- Flattop
Pedale VP VP-532
- 34.9mm diameter
- 0mm setback
- XSHORT/SHORT: 150mm travel seatpost : MID: 180mm travel seatpost ﾖ LONG: 210mm travel seatpost : XLONG: 240mm travel seatpost
- V-mount adapter
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Scheinwerfer CG-119PG-BLACK(1)
Rücklicht CG-404RG-BLK
Motor Bosch Performance Line SX
- integrated
Display Bosch Purion 400
Switch Bosch Mini Remote
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
Zulässiges Gesamtgewicht 140 kg
| Rahmengröße | XShort | Short | Mid | Long | XLong |
| Laufradgröße | 29" | 29" | 29" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 400 | 410 | 425 | 445 | 465 |
| TT Oberrohrlänge (mm) | 543 | 567 | 591 | 616 | 640 |
| CS Hinterbaulänge (mm) | 450 | 450 | 450 | 450 | 450 |
| HTA Steuerrohrwinkel (°) | 64 | 64 | 64 | 64 | 64 |
| STA Sitzrohrwinkel effektiv (°) | 78.5 | 78.5 | 78.5 | 78.5 | 78.5 |
| BD Tretlagerabsenkung (mm) | 27.5 | 27.5 | 27.5 | 27.5 | 27.5 |
| HT Steuerrohrlänge (mm) | 100 | 105 | 110 | 115 | 120 |
| FL Gabeleinbaulänge (mm) | 571 | 571 | 571 | 571 | 571 |
| R Reach (mm) | 420 | 443 | 466 | 489 | 512 |
| S Stack (mm) | 611 | 616 | 620 | 625 | 629 |
| WB Radstand (mm) | 1202 | 1228 | 1253 | 1278 | 1303 |
| SH Überstandshöhe (mm) | 753 | 757 | 761 | 768 | 774 |
| Str Stack To Reach Ratio Pc | 1.45 | 1.39 | 1.33 | 1.28 | 1.23 |
