- material: carbon
- 174 mm suspension travel
- 29x2,6" max. wheelsize
- 148x12 mm axle standard
- intube
Rahmengrössen XShort, Short, Mid, Long, XLong
Farbe GUNMETAL GREY (BLACK)
- Air
- 170 mm suspension travel
- Tapered
- 44 mm fork offset
- 29x2.6" max. wheelsize
- 2 Pos Lever
Schaltwerk Shimano XT M8130 LinkGlide 11
- 165 mm
Schalthebel Shimano SL -MT500-IL / Shimano XT M8130
- 4 piston
- 220 mm
- 203 mm
Steuersatz Acros ICR MERIDA INTEGRATED neck w/ Blocklock
Spacer 2*10 mm, 1*2.5 mm
Griffe MERIDA EXPERT EC
Schalthebelklemme JAGWIRE FLEX-SL:CP
- 10-50 teeth
- 11 speed
- 110x15 mm width front hub
- 148x12 mm width rear hub
- 28 mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- front 29"
- rear 27.5"
- 110x15 mm width front hub
- 32 spoke holes
- Centerlock
- 148x12 mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4 mm allen key
Speichen Black stainless
- 29x2.5"
- fold
- TR EXO+ 3C MaxxGrip
- 27.5x2.4"
- fold
- 3C DD MaxxTerra
Kette Shimano LG500
Pedale VP VPE-527
- 34.9 mm diameter
- 0 mm setback
- all sizes 30-230 mm travel seatpost
- V-mount adapter
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Schutzbleche C093-02F + C093-02R
Scheinwerfer Lezyne E-Bike Power STVZO E115, reverse MERIDA Custom Mount
Rücklicht Chance Good USB CG-214RG
- 85Nm
Akku Trendpower Internal Battery 600 Wh
Display Shimano SC-EN600
Switch Shimano SW-EM800-L
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
- Total weight of bike, rider and luggage
| Rahmengröße | XShort | Short | Mid | Long | XLong |
| Laufradgröße | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" |
| ST Sitzrohrlänge (mm) | 400 | 410 | 425 | 445 | 465 |
| TT Oberrohrlänge (mm) | 546 | 567 | 589 | 610 | 632 |
| CS Hinterbaulänge (mm) | 446 | 446 | 446 | 446 | 446 |
| HTA Steuerrohrwinkel (°) | 64.4 | 64.4 | 64.4 | 64.4 | 64.4 |
| STA Sitzrohrwinkel effektiv (°) | 78.5° | 78.5° | 78.4° | 78.4° | 78.3° |
| BD Tretlagerabsenkung (mm) | 9 | 9 | 9 | 9 | 9 |
| HT Steuerrohrlänge (mm) | 100 | 105 | 110 | 115 | 120 |
| FL Gabeleinbaulänge (mm) | 581 | 581 | 581 | 581 | 581 |
| R Reach (mm) | 419 | 439 | 459 | 479 | 499 |
| S Stack (mm) | 624 | 628 | 633 | 637 | 642 |
| WB Radstand (mm) | 1199 | 1221 | 1244 | 1266 | 1288 |
| SH Überstandshöhe (mm) | 776 | 770 | 765 | 760 | 755 |
