Weitere Informationen zu diesem Artikel finden Sie auf der
Homepage des Herstellers.
- material: aluminium
- 143 mm suspension travel
- 27.5x2.8" max. wheelsize
- 148x12 mm axle standard
- intube
Rahmengrössen XShort, Short, Mid, Long, XLong
Farbe DARK STRAWBERRY (BLACK)
- Air
- 150 mm suspension travel
- Tapered
- 44 mm fork offset
- 29x2.5" max. wheelsize
Federbein Rock Shox Super Deluxe Select
Schaltwerk Sram NX Eagle
- 165 mm
Schalthebel Limotec RM10 (For Sram mmX) / Sram NX Eagle 12
- 4 piston
- 200 mm
Steuersatz Acros ICR MERIDA EXTERNAL neck w/ Blocklock
Spacer 2*10 mm, 1*2.5 mm
Griffe MERIDA EXPERT EC
Schalthebelklemme JAGWIRE FLEX-SL:CP
- 10-50 teeth
- 12 speed
- 110x15 mm width front hub
- 148x12 mm width rear hub
- 28 mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 29"
- 110x15 mm width front hub
- 32 spoke holes
- 6 bolt
- 148x12 mm width rear hub
- 32 spoke holes
- 6 bolt
- including removeable lever, 6/4 mm allen key
Speichen Black stainless
- 29x2.4"
- fold
- 3C EXO MaxxTerra
Kette Sram SX Eagle
Pedale VP VPE-527
- 34.9 mm diameter
- 0 mm setback
- XS: 125 mm travel seatpost - S: 150 mm travel seatpost - M/L/XL: 200 mm travel seatpost
- V-mount
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Schutzbleche Winning EOF-204
Scheinwerfer Lezyne E-Bike Power STVZO E115, reverse MERIDA Custom Mount
Rücklicht Chance Good USB CG-214RG
- 85Nm
Akku Trendpower Internal Battery 750Wh
Display Shimano SC-EN600
Switch Shimano SW-EN600-L
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
- Total weight of bike, rider and luggage
| Rahmengröße | XShort | Short | Mid | Long | XLong |
| Laufradgröße | 29" | 29" | 29" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 400 | 410 | 425 | 445 | 465 |
| TT Oberrohrlänge (mm) | 543 | 564 | 585 | 607 | 628 |
| CS Hinterbaulänge (mm) | 449 | 449 | 449 | 449 | 449 |
| HTA Steuerrohrwinkel (°) | 66.5 | 66.5 | 66.5 | 66.5 | 66.5 |
| STA Sitzrohrwinkel effektiv (°) | 79.7° | 79.7° | 79.6° | 79.5° | 79.5° |
| BD Tretlagerabsenkung (mm) | 35.5 | 35.5 | 35.5 | 35.5 | 35.5 |
| HT Steuerrohrlänge (mm) | 100 | 105 | 110 | 115 | 120 |
| FL Gabeleinbaulänge (mm) | 557 | 557 | 557 | 557 | 557 |
| R Reach (mm) | 431 | 451 | 471 | 491 | 511 |
| S Stack (mm) | 616 | 620 | 624 | 628 | 633 |
| WB Radstand (mm) | 1191 | 1213 | 1235 | 1257 | 1280 |
| SH Überstandshöhe (mm) | 758 | 752 | 746 | 744 | 739 |
