| Modell + HP/EP | eONE-FORTY 675 EQ EP1 |
| Farbe (Herstellerbezeichnung) | SILK STEEL BLUE |
| Rahmen | eONE-FORTY LITE III- material: aluminium
|
| Motor | Shimano EP8- 85Nm |
| Display | Shimano SC-E5003A |
| Batterie | Simplo Internal Battery- 750Wh |
| Ladegerät | Simplo EU Charger- 4A |
| Gabel | Suntour ZERON 35-Boost LOR- Air
|
| Dämpfer | SUNTOUR RS-EDGE-TR-LO-R8-M6- lockout |
| Bremse vorn | Shimano M4100- 4 piston |
| Bremse hinten | Shimano M4100- 4 piston |
| Bremsscheibe vorn | Shimano RT30- 203 mm |
| Kettenblatt | Shimano CRE70-B- 34 teeth
|
| Kurbelgarnitur | Shimano FCEM600- 165 mm for all sizes |
| Schalthebel hinten | Shimano Deore RDM5100 11 |
| Schaltwerk | Shimano Deore RDM5100 11 |
| Kassette | Shimano M5100- 11-51 teeth
|
| Kette | KMC e11S EPT |
| Lenker | MERIDA EXPERT eTR- 780mm width
|
| Griffe | MERIDA EXPERT EC |
| Vorbau | MERIDA EXPERT eTRII- material: aluminium
|
| Steuersatz | MERIDA-8152 |
| Sattel | MERIDA EXPERT CC- V-mount
|
| Sattelstütze | MERIDA COMP TR- 30.9mm diameter
|
| Vorderreifen | MAXXIS REKON- 29x2.4"
|
| Hinterreifen | MAXXIS REKON- 27.5x2.6"
|
| Nabe vorn | Shimano MT400-B- 110x15mm width front hub
|
| Nabe hinten | Shimano MT400-B- 148x12mm width rear hub
|
| Felge | MERIDA COMP TR- 29mm inner width
|
| Innenlager | included |
| Pedale | VP VPE-537 |
| Scheinwerfer | LEZYNE E-BIKE POWER STVZO E115, reverse MERIDA Custom Mount |
| Rücklicht | Herrmans H-Cargo integrated in MERIDA MIK carrier |
| Gepäckträger | MERIDA MA006 |
| Schutzbleche | Fender:FA311-70A / 75E3 with SW803V-70 / 75, fender stay MA007, alloy rail |
| Ständer | Atranvelo ED-100-PC |
| Zuläss. Gesamtgewicht | 140 kg |
