- material: Aluminum
- 180mm suspension travel
- 29” x 2,6” max. wheelsize
- 148x12mm axle standard
- intube *
Rahmengrössen XShort, Short, Mid, Long, XLong
Farbe GUNMETAL GREY (BLACK)
- Air
- 180mm suspension travel
- Tapered
- 44mm fork offset
- 29x2.6" max wheelsize
- platform
Schaltwerk Shimano XT LG
- 160mm for all sizes
Schalthebel Shimano SL -MT500-IL / Shimano XT
- 4 piston
- 220 mm
- 203 mm
Steuersatz Acros ICR MERIDA EXTERNAL neck w/ Blocklock
Spacer 2*10mm, 1*2.5mm
Griffe MERIDA EXPERT TR
Schalthebelklemme Bosch clamp and screw for the Display / JAGWIRE FLEX-SL:CP
- 11-50 teeth
- 11 speed
- 110x15mm width front hub
- 148x12mm width rear hub
- 30mm inner width
- 6-Bolt
- Shimano HG
- material: aluminium
- Tubeless ready (tubeless tape and valves included)
- including removeable lever, 6/4mm allen key
- 29x2.5 "
- fold
- TR EXO+ 3C MaxxGrip
- 27.5x2.4 "
- fold
- 3C DD TR MaxxTerra
Kette Shimano LG500
Pedale VP 532
- 34.9mm diameter
- 0mm setback
- SHORT, MID, LONG and XLONG 30-230mm travel seatpost
- XSHORT 30-200mm travel seatpost
- V-mount adapter
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Schutzbleche RF-001 mini fender
- reverse MERIDA Custom Mount
Rücklicht USB REAR Light CG-214RG
Motor Bosch Performance Line CX
- 800Wh
Display Bosch Purion 400
Switch Bosch Mini Remote
weighed at frame size M
Zulässiges Gesamtgewicht 140 kg
| Rahmengröße | XShort | Short | Mid | Long | XLong |
| Laufradgröße | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" |
| ST Sitzrohrlänge (mm) | 400 | 410 | 425 | 445 | 465 |
| TT Oberrohrlänge (mm) | 556 | 577 | 604 | 630 | 652 |
| CS Hinterbaulänge (mm) | 435 | 435 | 435 | 435 | 435 |
| HTA Steuerrohrwinkel (°) | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 |
| STA Sitzrohrwinkel effektiv (°) | 78.5 | 78.5 | 78.5 | 78.5 | 78.5 |
| BD Tretlagerabsenkung (mm) | 12 | 12 | 12 | 12 | 12 |
| HT Steuerrohrlänge (mm) | 110 | 115 | 120 | 125 | 130 |
| FL Gabeleinbaulänge (mm) | 600 | 600 | 600 | 600 | 600 |
| R Reach (mm) | 415 | 435 | 460 | 485 | 505 |
| S Stack (mm) | 652 | 657 | 661 | 666 | 670 |
| WB Radstand (mm) | 1195 | 1218 | 1245 | 1272 | 1294 |
| Str Stack To Reach Ratio Pc | 1.57 | 1.51 | 1.44 | 1.37 | 1.33 |
