Modell + HP/EP | eBIG.NINE 700 EP2 |
Farbe (Herstellerbezeichnung) | MATT BURGUNDY RED |
Rahmen | eBIG.NINE LITE III- material: aluminium
|
Motor | Shimano EP8- 85Nm |
Display | Shimano SC-E7000 |
Batterie | Shimano E8036- 630Wh |
Ladegerät | Shimano EC-E8004- 4A charging current |
Gabel | Suntour RAIDON34 LOR- Air
|
Bremse vorn | Shimano M4100- 4 piston |
Bremse hinten | Shimano M4100- 4 piston |
Bremsscheibe vorn | Shimano RT30- 180 mm |
Kettenblatt | Shimano CRE70-12-B- 36 teeth
|
Kurbelgarnitur | Shimano FCEM600- 165 mm for all sizes |
Schalthebel hinten | Shimano XT RDM8100 Shadow+ 12 |
Schaltwerk | Shimano XT RDM8100 Shadow+ 12 |
Kassette | Shimano M6100- 10-51 teeth
|
Kette | KMC e12T EPT |
Lenker | MERIDA EXPERT eTR- 760mm width
|
Griffe | MERIDA EXPERT EC |
Vorbau | MERIDA EXPERT eTRII- material: aluminium
|
Steuersatz | MERIDA-8157 |
Sattel | MERIDA EXPERT CC- V-mount
|
Sattelstütze | MERIDA EXPERT CC- material: aluminium
|
Vorderreifen | Maxxis Rekon Race- 29x2.35"
|
Hinterreifen | Maxxis Rekon Race- 29x2.35"
|
Nabe vorn | Shimano SLX- 110x15mm width front hub
|
Nabe hinten | Shimano SLX- 148x12mm width rear hub
|
Felge | MERIDA COMP CC- 20mm inner width
|
Innenlager | included |
Pedale | VP VPE-527 |
Scheinwerfer | LEZYNE E-BIKE POWER STVZO E115, reverse MERIDA Custom Mount |
Rücklicht | USB REAR Light CG-214RG |
Ständer | CL-KA98, 29" |
Zuläss. Gesamtgewicht | 140 kg |
