- Rahmen: BIG.NINE CF3
- * material: carbon * 29 wheelsize * 148x12mm axle standard * BB92 bottom bracket standard
- Remote-Hebel: OneLoc
- Gabel: Rock Shox SID Select
- * Air * 100mm suspension travel * Tapered * Remote lockout * 42mm fork offset
- Vorderradbremse: Shimano XT
- * 2 piston
- Hinterradbremse: Shimano XT
- * 2 piston
- Bremsscheibe vorn: Shimano RT-MT800
- * 180 mm
- Bremsscheibe hinten: Shimano RT-MT800
- * 160 mm
- Kette: Shimano XT
- Kettenblatt: Shimano XT
- * 32 teeth * 170 mm-S, 175 mm-M up
- Kurbelgarnitur: 170 mm-S, 175 mm-M up
- Innenlager: Shimano MT800-PA pressfit
- Schaltwerk: Shimano XT M8100 Shadow+
- Kassette: Shimano XT
- * 10-51 teeth * 12 speed
- Griffe: MERIDA TEAM CC
- Lenker: MERIDA EXPERT CC
- * material: aluminium * 720mm width * flat
- Vorbau: MERIDA EXPERT CC
- * material: aluminium * 31.8mm diameter * -17° stem angle * S-70 mm, M-80 mm, L-90 mm, XL-100 mm, XXL-110 mm
- Steuersatz: FSA NO.55E
- Kompressor: AL cap with STS bolt+ ST stop nut
- Hinterachse: MERIDA COMP TR
- Sattel: MERIDA EXPERT CC
- Sattelstütze: MERIDA TEAM CC
- * material: carbon * 30.9mm diameter * 0mm setback * S-Flex
- Schalthebel hinten: Shimano XT
- Vorderreifen: Continental Race King 2.2
- * 29x2.2" * fold * RaceSport
- Hinterreifen: Continental Race King 2.2
- * 29x2.2" * fold * RaceSport
- Zubehör: MERIDA Multitool with saddlebox
- Laufradsatz: Reynolds TR 249
- * 110x15mm width front hub * 148x12mm width rear hub * 24mm inner width * Centerlock * Shimano 12 Speed * material: carbon * Tubeless ready (tubeless tape and valves included)
- Gewicht: 9.83
- weighed at frame size M and 29" wheels without pedals
