- material: aluminium
- 700x50C max. wheelsize
- 100x12/135x9mm axle standard
- BSA bottom bracket standard
- W-XS, W-S, W-M
Farbe SILK HIGH CREAM (BROWN)
- Tapered
- material: carbon
- 700x47C max. wheelsize
- mechanical
- 12 speed
- 42 teeth
- 170mm all sizes
Schalthebel Sram Eagle S200 MMX
- 2 piston
- hydraulic
- 180 mm
- 1.8 mm thickness
- 180 mm
- 2.3mm thickness
Steuersatz Acros ICR MERIDA external neck w/diecast splitring
Spacer 2*10mm, 2*2.5mm
Griffe MERIDA COMP TR
- 11-44 teeth
- 12 speed
- 23mm inner width
- 26mm height
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
Felgenband Stans 25mm tubeless tape installed
- 100x12mm width front hub
- 28 spoke holes, Centerlock
- Centerlock
Achse MERIDA EXPERT TR
Speichen Black stainless
Kette Sram Apex Flattop
Pedale VP VPE-892
- material: aluminium
- 27.2mm diameter
- 0mm setback
- 25% recycled material
- V-mount
Sattelklemme MERIDA EXPERT
| Rahmengröße | XS | S | M | L | XL |
| Laufradgröße | 28" | 28" | 28" | 28" | 28" |
| ST Sitzrohrlänge (mm) | 470 | 495 | 510 | 535 | 565 |
| TT Oberrohrlänge (mm) | 554 | 567 | 577 | 589 | 606 |
| CS Hinterbaulänge (mm) | 447 | 447 | 447 | 447 | 447 |
| HTA Steuerrohrwinkel (°) | 70.5 | 71 | 71 | 71 | 71 |
| STA Sitzrohrwinkel effektiv (°) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| BD Tretlagerabsenkung (mm) | 70 | 70 | 70 | 70 | 70 |
| HT Steuerrohrlänge (mm) | 130 | 140 | 160 | 185 | 210 |
| FL Gabeleinbaulänge (mm) | 415 | 415 | 415 | 415 | 415 |
| FO Gabelversatz (mm) | 45 | 45 | 45 | 45 | 45 |
| R Reach (mm) | 385 | 395 | 400 | 405 | 415 |
| S Stack (mm) | 569 | 580 | 599 | 623 | 646 |
| WB Radstand (mm) | 1051 | 1060 | 1071 | 1084 | 1103 |
| SH Überstandshöhe (mm) | 747 | 775 | 780 | 818 | 844 |
| Str Stack To Reach Ratio Pc | 1,48 | 1,47 | 1,50 | 1,54 | 1,56 |
