Weitere Informationen zu diesem Artikel finden Sie auf der
Homepage des Herstellers.
- material: carbon
- 174mm suspension travel
- 29" x 2,4" max. wheelsize
- 148x12mm axle standard
- removable battery
Rahmengrössen XShort, Short, Mid, Long, XLong
Farbe WARM SLATE GREY (GOLDEN BLACK)
- Air
- 170mm suspension travel
- Tapered
- 44mm fork offset
- 29x2.6" max wheelsize
Federbein Rock Shox Vivid Ultimate
- electronic
- 12 speed
Kurbel Sram S1000 Eagle E-MTB Crank, 160mm all sizes
Schalthebel Sram dropper lever MMX / Sram AXS Pod Controller
- 4 piston
- hydraulic
- 220mm
- 200mm
Steuersatz Acros ICR MERIDA INTEGRATED neck w/ Blocklock
Spacer 2*10mm, 1*2.5mm
Griffe MERIDA EXPERT TR
- 10-52 teeth
- 12 speed
- 110x15mm width front hub
- 148x12mm width rear hub
- 30mm inner width
- 6-Bolt
- SRAM XD
- material: aluminium
- Tubeless ready (tubeless tape and valves included)
- including removeable lever, 6/4mm allen key
- 29x2.4"
- fold
- TR
- Enduro casing
- Super soft compund
- 27.5x2.4"
- fold
- Enduro casing, soft compound
- Flattop
Pedale VP VP-532
- 34.9mm diameter
- 0mm setback
- all sizes 30-230mm travel seatpost
- V-mount adapter
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Schutzbleche RF-001 mini fender
Scheinwerfer Litemove SC160
Rücklicht Chance Good CG-214RG
- 120Nm, 750W
- 800Wh
- removable
Display Bosch Kiox 400C
Switch Bosch Mini Remote
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
Zulässiges Gesamtgewicht 140 kg
| Rahmengröße | XShort | Short | Mid | Long | XLong |
| Laufradgröße | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" |
| ST Sitzrohrlänge (mm) | 400 | 410 | 425 | 445 | 465 |
| TT Oberrohrlänge (mm) | 553 | 570 | 593 | 621 | 650 |
| CS Hinterbaulänge (mm) | 447 | 447 | 447 | 447 | 447 |
| HTA Steuerrohrwinkel (°) | 64 | 64 | 64 | 64 | 64 |
| STA Sitzrohrwinkel effektiv (°) | 78.5 | 78.5 | 78.5 | 78.5 | 78.5 |
| BD Tretlagerabsenkung (mm) | 10 | 10 | 10 | 10 | 10 |
| HT Steuerrohrlänge (mm) | 100 | 110 | 120 | 130 | 145 |
| FL Gabeleinbaulänge (mm) | 586 | 586 | 586 | 586 | 586 |
| FO Gabelversatz (mm) | 44 | 44 | 44 | 44 | 44 |
| R Reach (mm) | 425 | 440 | 460 | 485 | 510 |
| S Stack (mm) | 628 | 637 | 646 | 655 | 669 |
| WB Radstand (mm) | 1216 | 1235 | 1259 | 1289 | 1320 |
| SH Überstandshöhe (mm) | 757 | 762 | 762 | 765 | 769 |
Angaben zur Produktsicherheit
Hersteller:
MERIDA INDUSTRY CO., LTD., P.O. Box 56, Yuanlin, Taiwan R.O.C.
Kontakt: www.merida-bikes.com
Verantwortliche Person:
MERIDA & CENTURION Germany GmbH, Blumenstraße 49-51, 71106 Magstadt, Deutschland
Kontakt: www.mcg-parts.de
